AHU servicing
AHU maintenance in Al Ushairiyah
In Al Ushairiyah, north-east Jeddah, Alrabih maintains air handling units in factories, warehouses and large industrial complexes. Controlling temperature, humidity and fumes is vital for product protection and worker safety, and any unit fault affects productivity and wellbeing.
- Balanced airflow
- Clean air
- Quiet operation
Clients We're Proud to Serve
Organisations and companies that trusted Alrabih with their projects.
When an AHU needs attention
- 1
Weak airflow or smells in the building
A clogged filter or dirty cooling coil cuts airflow and carries a musty smell through Jeddah's humid air. Occupants complain and productivity falls before anyone identifies the source.
- 2
Unusual noise from the plant room
A grinding or vibrating fan usually points to a worn bearing, a slack belt or an unbalanced blade. Delaying the diagnosis can turn a simple fix into a full motor replacement.
- 3
Uneven distribution between zones
One zone too cold and another too warm in the same building usually means a balancing valve not working or a stuck damper. The site survey decides which dampers and valves need adjusting or cleaning.
Who it's for
Your office staff are complaining about poor cooling
We inspect the unit under load, check filters, coil and dampers, and restore balanced airflow across every office zone.
Ask on WhatsAppYou run a medical facility or a large hall
We check the fresh-air intake, dampers and drain pan, verify the drain fall, and issue a written report documenting the condition of every component.
Ask on WhatsApp
What AHU servicing covers
- Filters checked, cleaned or replaced
- Belts and bearings checked, tensioned
- Coil and drain pan cleaned
- Dampers and fresh-air intake set
- Airflow, noise and motor measured
How we work
How we work
- 1
Unit and system survey
We review the system layout, unit sizes and count, run the unit and record airflow, pressure and noise readings before touching anything.
- 2
Mechanical inspection
We open the access panel and inspect belts, bearings, the fan blade and mounts, recording what needs tensioning or replacing before starting work.
- 3
Clean and adjust
We clean the coil and drain pan, verify the drain fall, adjust dampers and valves, and replace worn filters, belts and bearings as needed.
- 4
Performance check and handover
We run the unit again, measure airflow and compare it with the opening reading, then give you a brief written report of what was done and anything that needs follow-up.
Planned servicing or breakdown response?
| Alrabih | The usual way | |
|---|---|---|
| Filters and coils | Inspected and cleaned regularly | Ignored until failure |
| Belts and bearings | Changed before they fail | Found after the unit stops |
| Air quality | Clean and balanced airflow | Ongoing occupant complaints |
| Condition report | Written after every visit | No record kept |
| Fresh-air intake | Checked and adjusted each visit | Neglected until air quality worsens |
Everything your AC needs, from one team
From system design and duct fabrication to installation, commissioning and maintenance.
Split AC installation
Request this serviceDuct installation
Request this serviceCentral AC installation
Request this serviceDuct fabrication
Request this serviceCold room installation
Request this serviceElectro-mechanical works
Request this serviceChiller & AHU installation
Request this serviceHVAC design
Request this serviceAC repair & faults
Request this serviceAC cleaning
Request this serviceRefrigerant charging
Request this serviceCentral AC maintenance
Request this serviceChiller maintenance
Request this serviceAC removal & refitting
Request this serviceDuct cleaning & sanitising
Request this serviceAC servicing by brand
Request this serviceOperation & maintenance contracts
Request this serviceAHU maintenance
Request this serviceFridge & freezer service
Request this serviceCold rooms
Request this serviceDisplay fridges & chillers
Request this serviceFactory HVAC
Request this serviceWarehouse HVAC
Request this serviceVilla & home HVAC
Request this serviceHotel HVAC
Request this serviceSchool HVAC
Request this serviceHospital HVAC
Request this serviceMosque HVAC
Request this serviceMall & retail HVAC
Request this serviceRestaurant & cafe HVAC
Request this service
Some of our work
Ductwork, rooftop units and diffusers, from work we've completed in Jeddah.
Customer reviews
What our customers say
- Muhammadramzan 2641
“MashaaAllah. Services are so good. Behaviour and kindness 100/100. Prices are less then Market. Fully recommended”
- shahzeb armani
“Wow. Prices are so comfortable. Outstanding services. People are so talented and nice”
- Tawfik AlyawerLocal Guide
“U can find all u need for air conditioning”
Your satisfaction matters to us! If you had a great experience with us, we'd love a 5-star rating and a kind review.
Worked with us? Leave a reviewService areas
We come to you anywhere in Jeddah
From Al Shiraa and Al Yaqout in the north to Al Thaghr and Al Quraiyat in the south, with our base in Al Aziziyah.
What sets this district apart
Al Ushairiyah is an active industrial zone with large factories, warehouses and high-ceiling production halls, where AHUs run at very high intensity in harsh conditions (heat, humidity, fumes, industrial dust). Each factory or warehouse typically relies on one or more units for air distribution and temperature and humidity control, and any downtime or maintenance delay can halt production or endanger workers. The team works efficiently on inspecting, cleaning and servicing coils, bearings, belts and filters, and keeping operations running with minimal production impact.
Al Ushairiyah sits in north-east Jeddah, a dense industrial zone with factories, production halls and warehouses.
Most factories and warehouses here have heavy-duty industrial AHUs with temperature, humidity and pressure sensors.
The AC setup in Al Ushairiyah
- 1
Heavy-duty industrial AHUs
Large factories and warehouses have very robust units designed for high intensity and harsh conditions.
- 2
Advanced cooling, heating and dehumidification systems
Most units have powerful cooling and heating coils and dehumidification systems to meet industrial standards.
- 3
High-capacity filters for heavy dust
Units are fitted with high-grade filters capable of handling heavy industrial fumes and dust.
Before the visit
Before our visit in Al Ushairiyah
- 1
Schedule maintenance at the best time
Coordinate with the production manager to choose a maintenance time outside main production hours or during set shifts.
- 2
Ensure team safety on the industrial site
Provide necessary safety equipment and inform our team of any industrial hazards (fumes, dangerous materials, running machinery).
- 3
Prepare access and space around the unit
Confirm safe access to the unit and adequate space around the ceiling or location for the team to work safely and efficiently.
More districts for AHU maintenance
Other services in Al Ushairiyah
FAQ
Questions about AHU maintenance
What is the difference between AHU servicing and duct cleaning?
AHU servicing focuses on the mechanical and thermal parts inside the unit itself: filters, coil, drain pan, bearings and dampers. Duct cleaning removes dust from the distribution network. The two jobs use different tools and address different problems, and we offer each as a separate service.
Can the AHU be serviced while the building is occupied?
In many cases yes, depending on the system layout and the number of units. If the building can run a standby unit while we work on another, servicing continues without cutting cooling to any zone. The technician confirms this at the first survey.
How does Jeddah's humidity affect AHUs specifically?
High humidity loads the dehumidification coil harder and speeds up algae growth in the drain pan, blocking the drain much faster than in dry climates. For that reason we give the pan clean and the drain fall check particular attention when servicing AHUs in Jeddah.
When does a bearing need replacing rather than just greasing?
If a bearing shows audible grinding, measurable heat on the housing or radial play when checked by hand, greasing will not fix it. We measure and inspect on site and decide the right action there, because bearing type and size vary from one unit to another.
How do you tell whether the fan needs balancing rather than just lubricating the bearings?
Continuous vibration with a steady hum usually points to an unbalanced fan wheel or dirt build-up on the blades, while an irregular grating sound comes from the bearing itself. The technician measures vibration on the frame and on the shaft; if it is higher on the frame he balances the wheel, and if it is higher on the shaft he inspects the bearing and decides whether to replace it or lubricate it depending on the degree of wear.
The AHU serves a huge production area, can you service it without stopping work?
It depends on system design. We try to work outside production hours or during set shifts in full coordination with the production manager.
Industrial fumes and dust clog the coils and filters fast, how often do you recommend cleaning?
In factories, filters typically need weekly inspection and coils every two to three weeks due to harsh conditions.
Extreme heat and humidity from production affect unit lifespan, do you recommend preventative maintenance?
Yes, monthly or quarterly preventative maintenance is essential in factories to restore unit efficiency and avoid sudden breakdowns.
The warehouse is far from town and the electrical wiring is old, does that affect service?
We inspect the unit's electrical connections for safety before work. If there are circuit issues, we recommend upgrading them.
